Περιγραφη
SPECIFICATIONS:
• Pixel Pitch: 4.81mm (0.19”)
• LED Configuration: 3-in-1 SMD1921 LED
• Pixel Density: 104×104; 43264 (dot/m2)
• Panel Size :19.75” x 19.75” x 4” / 500 x 500 x 100mm
• Module Quantity: 2
• Module Size: 250 x 500mm
• Module Resolution: 52 x 104 pixels
• Panel Weight: 20 lbs. / 9kg.
MECHANICAL RATINGS:
• Surface Flatness: Gaps<0.5mm
OPTICAL RATINGS:
• Brightness: 4000 NITS
• View Angle: Horizontal 140°/Vertical 140°
• Gray Scaler: 14-bit
• Brightness Adjustment: 0~100% / 100 Levels
• Processing: 14-bit
POWER SUPPLY:
• Input Voltage: 100~240V 50-60Hz
• Max. Power Consumption: 180W/per panel
• Ave. Power Consumption: 60W/per panel
• Connections Power/Data: Power = IP65 Locking Power In/Out; Data = IP65 Locking RJ45 In/Out
CONTROL SYSTEM:
• Control Mode: Nova Star Synchronous System with Control via DVI
• Frame Update Frequency: 50-60Hz
• Scan Mode: 1/16
• Refresh Rate: 1920Hz
• Support Input : Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
• Control Distance. Ethernet Cable <100m or Fiber Optic > 120m
• Support VGA Mode : 1024 x 768, 1280 x 1024, 1600 x 1200, 1920 x 1280
• Brightness Control : Pixel, Module, Cabinet
Environmental:
• Operating Temperature: Celsius : -10° to +50°; Fahrenheit : -14° to +122°Humidity: 10-90%
• Operating Life/MTBF: @ 50.000 hours
• Protection Level : IP65 Outdoor rated
• Out of Control Rate <0,02%
• Listings: cETL, CE, FCC Class A
