QSC SPA2-60
Ενισχυτής 1/2 RU, 2 Καναλιών με Energy Star Rating. Λειτουργία Stereo με 60 Watt ανά κανάλι στα 8 & 4 Ω, λειτουργία Bridge στα 200 watt/8Ω & 4Ω, 250 watt στα 70V ή 100V.
Περιγραφη
Τεχνικά Χαρακτηριστικά:
Stereo Mode, watts per channel
8Ω dynamic, both channels driven: 60 watts
4Ω dynamic, both channels driven: 60 watts
Bridged Mode, watts per channel
8Ω & 4Ω dynamic: 200 watts
70V & 100V: 250 watts
Signal to Noise (A weighted, 20 Hz–20 kHz) >100 dB
Input Sensitivity 1.23 Vrms (+4 dBu)
Maximum Voltage Gain 25.0 dB
Frequency Response (20 Hz – 20 kHz) +0.1 dB, -0.1 dB
Maximum Input Level +12.3V (+24 dBu)
Front Panel Indicators Power, per channel Signal, per channel Protect/Limit
Highpass Filter Switchable 80 Hz when Bridged in 70V & 100V
Controls 4Ω/8Ω/70V Bridge Highpass On/100V Bridged Highpass On per channel pair
Dimensions (HWD) 43 x 220 x 241 mm (1RU)
Weight 1,1 kg
Agency Approvals UL, CE, ENERGY STAR, RoHS/WEEE compliant, FCC Class B (Conducted and Radiated emissions), UL 2043 with PL-Kit
